Product Details
Mintech MV-2500 is a processing equipment specially designed to meet the high-precision cutting of non-metallic materials; equipped with imported RF metal-encapsulated lasers; all-steel seamless welding, 800° aging annealing heat treatment, super large CNC gantry Milling precision machining; fast processing speed; X, Y, Z axis configuration of imported ball screw and imported guide rail drive and servo drive; high standard assembly technology, strict inspection standards, has been recognized by customers since its launch.
Machine configuration list
Configuration name | description | Remarks |
Laser power | RF Germany Rofin SR151 250 W | Optional 180W, 350W |
Dimensions | 4000×2000×1300mm | |
Processing stroke | X: 1300, Y: 2500mm | MV3000 type 1500 × 3000mm |
working desk | Triangular aluminum strip support | |
Alignment device | infrared | |
the fastest speed | 20m/min | Fastest |
Acrylic maximum cutting thickness | 40mm | Perfect cutting |
X/Y axis positioning accuracy | ±0.05 | Mm/m (mm/m) |
X/Y axis repeat positioning accuracy | ±0.05 | Mm |
Cutting head | Lens fast precision cutting head | Independent research and development |
Focal length adjustment | electric | |
Mechanical transmission system | Ball screw for X/Y axis | Taiwan import |
X/Y/Z uses TBI rail | Taiwan import | |
Dedicated cooling system | Temperature control accuracy of ±0.5 °C, a variety of alarm protection functions: compressor delay protection; compressor overcurrent protection; water flow alarm; temperature super high, ultra low alarm
| Special domain |
Optical path system | Flying light path, sealed and dustproof | |
Optical lens cooling system | ||
Exhaust system | Intelligent partition to start the exhaust | |
sport control | Offline control | 乐创LEETRO |
Support software | CAD, Coredraw, etc. | |
server Driver | MITSUBISHI | Mitsubishi Japan |
HMI | High resolution capacitive touch screen | FLEXEM |
Fan control | Touch screen | Self-configuration |
