1

Pixel composition

Arrangement form

Vertical

2

Pixel tube spacing

3.91mm

3

Pixel composition

1R1G1B (three in one)

4

Lamp bead model

SMD1921 (chip ratio 3:6:1)

5

Physical density

65536 dots/㎡

6

Module/box size

Module size

250 width x 250 height (mm)

7

Module resolution

64 width x 64 height (dot)

8

Box size

500 (width) × 1000 (height) mm

9

Box weight

22.5KG/pc

10

Box thickness

9cm (including module thickness)

11

Full screen parameters

Out of control point

≤3/100000

12

Unit module splicing seam

The size of the unit board gap splicing seam is the same, and ≤ 2mm

13

Optimal distance

5-60m

14

Perspective

Horizontal 140°, vertical 140°

15
