Application industry advertising sculpture, architectural model, leather clothing, craft gifts, musical instrument panel, fingerboard sculpture, inlay cutting: printing, packaging; furniture: seat cover, cushion; plush toys
Applicable materials: cloth, leather, plush material, synthetic fiber, paper and other non-metallic flexible heddle materials
X and Y adopt three imported linear square rails.
High-strength transmission mechanism to ensure the smooth running of the machine.
Professionally designed high-strength fuselage structure.
X and Y adopt deceleration drive structure.
Three-phase stepper motor drive ensures more stable low-speed cutting.
The reflection adopts silicon mirror and aspherical focusing mirror.
True color display, direct preview of graphics, realize continuous fast curve cutting and shortest processing path optimization.
Support USB, Ethernet, U disk.
CORELDRAW, AUTOCAD output directly.
Configure water cut protection and red light positioning.
Technical parameters
Machine model 1325/1625/1825 resolution ≤4000dpi
Laser power 80/100/120/150W Motor Three-phase stepper motor
power supply
220V±10%50HZ
110V±10%50/60HZ
Positioning accuracy <0.15mm
Total power <1500W Interface communication USB, WEB
Working area 1300mm×2500mm Working temperature 5℃~45℃
Engraving speed 0-64000mm/min Working humidity 5%-90% (no condensation)
Cutting speed 0-36000mm/min
Precautions
1.During the operation of the machine, the operator is strictly prohibited to leave to avoid fire.
2.After each startup, check whether the submersible pump is out of water. It is strictly forbidden to start working without the pump.
3.It is strictly forbidden to start the machine without grounding. The ground wire of the laser power supply must be connected to the ground, and must not be connected to doors, windows, water pipes and other facilities. The ground wire should be connected to the outdoor ground.
4.The water temperature of the water container must be controlled below 25 degrees. If the water temperature is too high, the circulating water should be replaced. It is best to use purified water for circulating water, and ensure that the water is clean and free of impurities. Replace the circulating water regularly.
5.Due to the laser and high voltage parts inside the machine, non-professionals are strictly prohibited from disassembling machine parts without authorization.
6.The fan must be turned on when engraving to avoid contaminating the lens and focusing lens. It is strictly prohibited to place flammable and explosive materials near the equipment to avoid fire.
7.It is strictly prohibited to use during thunderstorms.
8.It is strictly forbidden to plug or unplug the power cord and communication cable when the power is on.
9.During operation, abnormal phenomena such as no light output or collision of the coordinate system are found, and the power supply should be cut off first, and then the machine should be turned on after troubleshooting.
10.The guide rails should be cleaned regularly.
