Model:
RM08AGMC-D/RM08AAMC-D/RM00AHMC-D-T
Product Description:
5000*8 mm, 1600 pcs COB LEDs, bare board series, constant voltage 24Vdc, flexible LED strip ( white 10W)
5000*8 mm, 2560 pcs COB LEDs, bare board series, constant voltage 24Vdc, flexible LED strip ( white 12W)
5000*10mm, 3600 pcs COB LEDs, bare board series, constant voltage 24Vdc, flexible LED strip ( white 20W) used with profile.
Features:
1. Linear luminescence without light spot;
2. COB technology, anti-sulfur;
3. High CRI ≥90;
4. Low attenuation, long life,warranty of 5 years.
P/N | LED Color | CT (K) WL (nm) | CRI | SDCM | Beam Angle (° ) | Luminous Flux (lm/m) | Luminous Efficacy (lm/W) | Working voltage (V DC) | Working current (mA) | power (W/m) | ||
1m[39.37in] | 5m[196.85in] | 1m[39.37in] | 5m[196.85in] | |||||||||
RM0801MC-D | White | 2700 | ≥90 | 3 | 140 | 800 | 80 | 24 | 415 | 1666 | 10 | 40 |
White | 3000 | ≥90 | 3 | 140 | 800 | 80 | 24 | 415 | 1666 | 10 | 40 | |
White | 4000 | ≥90 | 3 | 140 | 930 | 93 | 24 | 415 | 1666 | 10 | 40 | |
White | 6500 | ≥90 | 3 | 140 | 1060 | 106 | 24 | 415 | 1666 | 10 | 40 | |
RM0802MC-D | White | 2700 | ≥90 | 3 | 140 | 960 | 80 | 24 | 500 | 2000 | 12 | 48 |
White | 3000 | ≥90 | 3 | 140 | 960 | 80 | 24 | 500 | 2000 | 12 | 48 | |
White | 4000 | ≥90 | 3 | 140 | 1104 | 92 | 24 | 500 | 2000 | 12 | 48 | |
White | 6500 | ≥90 | 3 | 140 | 1236 | 103 | 24 | 500 | 2000 | 12 | 48 | |
RM0003MC-D-T | White | 2700 | ≥90 | 3 | 140 | 1440 | 72 | 24 | 830 | 3333 | 20 | 80 |
White | 3000 | ≥90 | 3 | 140 | 1440 | 72 | 24 | 830 | 3333 | 20 | 80 | |
White | 4000 | ≥90 | 3 | 140 | 1760 | 88 | 24 | 830 | 3333 | 20 | 80 | |
White | 6500 | ≥90 | 3 | 140 | 1900 | 95 | 24 | 830 | 3333 | 20 | 80 |
Others:
P/N | IP Grade | OperatingTemp | Storage Temp | Standard length | Max. cascading length | COB Qty (pcs/m) | Weight | |||||
(℃) | (℉) | (℃) | (℉) | (m) | (inch) | (m) | (inch) | (g/m) | (lb/m) | |||
RM0801MC-D | IP20 | -25~+60 | -13~+140 | -25~+70 | -13~+158 | 5 | 196.8 | 5 | 196.8 | 320 | / | / |
RM0802MC-D | IP20 | -25~+60 | -13~+140 | -25~+70 | -13~+158 | 5 | 196.8 | 5 | 196.8 | 512 | / | / |
RM0003MC-D-T | IP20 | -25~+60 | -13~+140 | -25~+70 | -13~+158 | 5 | 196.8 | 5 | 196.8 | 720 | / | / |
Notes:
1. Testing environment temperature: 25±2℃ [77±3.6℉];
2. The actual data of each single product may differ from above typical data which are subject to change without prior notice;
3. Bending diameter ≥50mm, not suitable for channel letter.
4. The above “--” means the parameters are not required temporarily.
