Product Description:
1pc 2835 SMD LEDs, 42*16*7.5mm, white PVC shell, equipped with optical device, plastic coated series, constant current, 12Vdc, LED modules.
Features:
1. High efficacy-- up to 160lm/W;
2. Better uniformity with the secondary optical big bat wing light distribution;
3. More Stable performance by the chip with constant current tech;
4. Warranty of 5 years;
5. IP rating of IP65.
Parameters
P/N | LED Color | CCT (K) WL (nm) | CRI | SDCM | Beam Angle (°) | Luminous | Luminous Efficacy (lm/W) | Working voltage (V) | Working current (mA) | Power (W/piece) |
M8R1TB | Pure White | 6000 | ≥70 | —— | 160 | 58 | 160 | 12 | 30 | 0.36 |
Others:
P/N | IP Grade | Operating Temp | Storage Temp | Standard cascading qty (pcs) | Single-ended max. cascading qty(pcs) | Double-ended max. cascading qty(pcs) | Weight | |||
(℃) | (℉) | (℃) | (℉) | (g/piece) | (lb/piece) | |||||
M8R1TB | IP65 | -25~+60 | -13~+140 | -25~+70 | 13~+158 | 40 | 40 | 80 | 7 | 0.015 |
Notes:
1. Testing environment temperature: 25+2*C[77+3.6"F];
2. The actual data of each single product may differ from above typical data which are subject to change without prior notice;
3. The above“--means the parameters are not required temporarily.
